Product Details:
|
| Type: | EV Charger Wallbox, Wall-mounted EV Charging Station, Ev Charging Station | Year: | 2016-2016, 2008-2010, 2008-2011, 2008-2012, 2008-2016, 2015-2016, 2017-2019, 2013-2013, 2012-2013, 2017-2019, 2014-2016, 2015-2016, 2013-2016, 2016-2019, 2012-2013, 2017-2019, 2008-2010, 2019-, 2020-, 2019-, 2018-, 2021-, 2021-, 2019-, 2021- |
|---|---|---|---|
| Model: | S, Model Y RWD Long Range, Model3, X, Roadster, TeslaRoadster, MODEL S, MODEL Y (5YJY), Modelx, Model X, Model Y AWD Long Range, Model Y AWD Performance, Model 3 Performance, Model X 70D, MODELS, MODEL 3 (5YJ3) | Function: | APP Control, Screen Display, Waterproof & Dustproof, Lightning Protection, Overvoltage Protection, Temperature Protection, Short Circuit Protection, Leakage Protection |
| Car Fitment: | Tesla | Charging Port: | 1port, Wireless With No USB Port |
| Connection: | Build-in WiFi, ID Card | Voltage: | 8A-48A |
| Warranty: | 2 Years | Product Name: | EV AC Charging Station |
| Input/Output Voltage: | 400VAC 50/60Hz 1Phase | Max Power: | 22kW |
| Standby Power: | <3W | Humidity: | Max.95%(non-regulating) |
| User Interface: | LED(RGB)/LCD(4.3'')/Touch Button/RFID(mifare ISO&IEC 14443A) | Standards: | IEC 62196 Type 2 |
| Charging Interface: | IEC 61851-1 | IP Degree: | IP 55 |
| Operating Temperature: | -30~55℃ | Port: | Shanghai Port, Yiwu Port, And According To Your Needs |
Technical Features | ||||||||||||
Input/Output Voltage | 100~240VAC 50/60Hz 1Phase | 400VAC 50/60Hz 3Phase | 400VAC 50/60Hz 3Phase | |||||||||
Output Current | 8A/10A/13A/16A/22A/32A | 8A/10A/13A/16A | 8A/10A/13A/16A/22A/32A | |||||||||
Max Power | 7kW | 11kW | 22kW | |||||||||
Product Size | 385*284*80(mm) | |||||||||||
Weight | ~4.0kg | ~3.5kg | ~4.9kg | |||||||||
Cable Length | 5m | 5m | 5m | |||||||||
Standby Power | ＜3W | |||||||||||
Communication | Wi-Fi 802.11b/g/n@2.4GHz | |||||||||||
User Interface | LED(RGB)/LCD(4.3'')/RFID(mifare ISO&IEC 14443A) | |||||||||||
Protocol | OCPP1.6j | |||||||||||
Standards | IEC 61851-1 | |||||||||||
Charging Interface | IEC 62196 Type 2 | |||||||||||
IP Degree | IP55 | |||||||||||
Operating Temperature | -25~+50℃ | |||||||||||
Humidity | Max.95%(non-regulating) | |||||||||||
Protection | Overvoltage Protection, Undervoltage Protection, Overcurrent Protection, Residual Current Protection, PEN Fault Protection, Overtemperature Protection, CP Protection, Emergency Stop Protection. | |||||||||||
Note | Charging Interface can be changed according to customer needs | |||||||||||
